MRB wireless People counter HPC005

Short Description:

Wireless installation, plug and play

up to 40 meters long distance detection range.

Anti-light intererence

Long better life for 1-5 years

LCD display to check data easily

Chain stores suitable, Occupancy Control

OEM and ODM, API and Protocol available




Product Detail

Product Tags

This is a wireless people counter that can be transmitted without WIFI, Many of our people counters are patented products. In order to avoid plagiarism, we did not put too much content on the website. You can contact our sales staff to send you more detailed information about our people counter.

In the era of big data, People counter makes data more accurate and makes business easier. Infrared people counter is suitable for libraries, high-speed rail stations, mobile phone stores, talent markets, telecommunications business halls, government offices, supermarkets, clothing chains, In major airports, science and technology museums and other places, unlike the axis people counter, the people counter of MRB is only half the size of a credit card. It is extremely convenient to install, two-way counting, intelligently distinguishing the direction of personnel entry and exit, and installation does not require any wiring. The maximum detection door is 40 meters wide, wireless data transmission, and the wireless transmission distance is much longer than that of a wireless router. People counter uses lithium-ion batteries for power supply, which can last for about 2 years, which is also different from axis people counter.

infrared-people-counter

Product advantages of MRB Infrared people counter

1. The design of people counter is simple and generous. The appearance design of the new counter is more concise, screw installation, support paste.
2. Longer battery life, people counter battery life can reach one and a half years, 3.6V large-capacity lithium battery, voltage 1.5-3.6V, using AA (No. 5), better adaptability.
3. Increase the LCD display on the infrared people counter, the data in and out are clear at a glance, and you can see clearly.

People-counter-03

4. Data transmission of people counter is stable. The data transmitted from the passenger flow counter to the data receiver is all encrypted data, which does not interfere with other devices and is safer.
5. Prevent the interference of light to the people counter more effectively, and solve the counting error caused by the change of ambient light.

infrared-people-counter-04

6. Real-time output data through the LED advertising screen on our infrared people counter, and the statistical data can be projected to the LED advertising screen through the protocol using software for real-time monitoring.
7. MRB People counter Can penetrate the glass to work normally without interference from glass doors and windows
8. Once the incoming infrared rays of the People counter are blocked by people or objects for more than 5 seconds, the display will show the blocked pattern, and the LED light in the middle of the RX will flash to indicate that there is obstruction, and the data will be reported to the data receiver. There will also be related records and tips in the software of the people counter.
9.Satisfy various customized requirements, customer's LOGO can be added to the people counter body or gift box.
10.MRB people counter wider distance: up to 1-40 meters long distance installation.
11. This people counter can be used for Occupancy control through software

People-counter-01
infrared-people-counter3

Specification

Model HPC005
General  People counter
Power Supply 1.5v/ 3.6v AA or lithium battery for sensors; Adaptor/ USB powered for DC
Weight 400g
Dimension 2.5 x 2.3 x 0.98"
Operating Temperature -10~ 40℃
Color White, or Customized
Installation All kinds of stores, library, Museum, Hospital, School
Parameters
Operating Current for Receiver (RX) 180μA
Static State Current for Receiver (RX) 70μA
Operating Current for Transmitter (TX) 200μA
Static State Current for Transmitter (TX) 80μA
Detection Way Infrared Rays
Counting Way Straightaway Shot and Shade and then Count
Data Transmitter Period 5 Minutes from RX to DC - customized; Immediately - DC to software
RF Transmission Frequency 433MHz, Encrypted
Connection Way RX to DC by RF Transmission, DC to computer by USB cable;
API Yes
Software
Standalone software For signal store, above windows 2003
Network software For chain stores, above windows 2003 and SQL2005 serve.
Installation
Height 1.2meter, face to face
Wide ≤20 meters
Fixed Way Screws or Stickers
Range from Sensors to DC ≤40 meters

HPC005 infrared People counter can also be used as an Occupancy counter for Occupancy control application in stores, public areas or public transportation areas:

People-counter-02
infrared-people-counter2
People-counter-04
infrared-people-counter1

FAQ for HPC005 Infrared people counting system:

  1. 1.Can I install HPC005 infrared people counter myself after I buy it with good price? Is the installation complicated?

The installation is very simple. You only need to stick the sticker on the back of the counter body and stick it on the wall or other surface.

  1. 2.What should I pay attention to during the installation of HPC005 IR beam counter?

Equal height, face to face, no shelter in the middle, try to avoid strong light, the direction of entry and exit shall be installed correctly, and there shall be entry and exit signs on the receiver.

3.Does the HPC005 infrared people counter need to be plugged in? Or batteries? What kind of battery is it?

infrared people counter

It can work without plug-in. It can use 1.5V ~ 3.6V AA battery. Generally speaking, it can be used for 1 to 3 years. It mainly depends on the size of human traffic and the frequency of uploading data to the server.

4.Can I view the incoming and outgoing data of HPC005 infrared traffic counter anywhere?

Yes, we provide online software and stand-alone software. The data will be uploaded to the server in real time and integrated. You can query the counter or summary information of any store anywhere.

5.What is the accuracy of HPC005 infrared beam counter?

If there is no strong light interference and the installation is correct, the accuracy can reach more than 90%, and even more than 95% in the factory environment. However, generally speaking, the environment of the customer's actual installation site is relatively complex. This should be adjusted according to the actual installation site to achieve the highest accuracy possible.

6.I have ERP or other software. I want to integrate with your HPC005 infrared counter, so that I can directly read the data of your equipment with my own software, is that OK?

Infrared beam counter
QQ截图20210818111901

 Answer:

As a more than 15 years People counter manufacturer supplier,we have been working on this for many years for customer’s conveniences, Yes, we provide protocol and API. You can operate according to our prompts. After the connection is successful, you can use your own software to view the data in the background.

  1. 7.How long does your product provide warranty service by manufacturer?

Generally speaking, we provide 2-year warranty service. For our dealers, we provide 3-5-year warranty service. Dealers all over the world are welcome to contact us to jointly explore the market. We work with you with a full range of high-quality people counters to obtain a higher local market share.

HPC005 wireless People counter video

If you have other counting needs, we, as a professional people counter manufacturer and supplier, we can provide you with different counters at good price and cost,

such as counting cars, we have vehicle counters,

counting passengers, we have passenger counters,

counting Animals, we have AI counters, etc.

and in terms of technology, we have 2D, 3D, AI, IR, etc.

OEM and ODM orders are welcomed at anytime.
